PERFORMANCE SERIES 2.5 SMOOTH BODY IFP HTO SHOCK

$329.95

PERFORMANCE SERIES 2.5 SMOOTH BODY IFP HTO SHOCK

Low Stock

Find a Retailer

FOX 2.5 Performance Series HTO shock is a bolt-on shock loaded with position-sensitive technology, vehicle-specific valving, and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen, optimizing damping.

Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed; HTO is particularly beneficial after installing heavier, aggressive tires and applications lifted higher than OEM specification.

Bolt-on 2.5 Performance Series HTO shocks to increase damping capacity and ride in comfort with position-sensitive rebound control.

987-24-010 Also Fits

Year Make Model Drive Type Position Lift Height Price
2020 Chevrolet Silverado 2500 HD All Front 1.5-2.5 $329.95
2021 Chevrolet Silverado 2500 HD All Front 1.5-2.5 $329.95
2022 Chevrolet Silverado 2500 HD All Front 1.5-2.5 $329.95
2023 Chevrolet Silverado 2500 HD All Front 1.5-2.5 $329.95
2024 Chevrolet Silverado 2500 HD All Front 1.5-2.5 $329.95
2020 Chevrolet Silverado 3500 HD All Front 1.5-2.5 $329.95
2021 Chevrolet Silverado 3500 HD All Front 1.5-2.5 $329.95
2022 Chevrolet Silverado 3500 HD All Front 1.5-2.5 $329.95
2023 Chevrolet Silverado 3500 HD All Front 1.5-2.5 $329.95
2024 Chevrolet Silverado 3500 HD All Front 1.5-2.5 $329.95
2020 GMC Sierra 2500 HD All Front 1.5-2.5 $329.95
2021 GMC Sierra 2500 HD All Front 1.5-2.5 $329.95
2022 GMC Sierra 2500 HD All Front 1.5-2.5 $329.95
2023 GMC Sierra 2500 HD All Front 1.5-2.5 $329.95
2024 GMC Sierra 2500 HD All Front 1.5-2.5 $329.95
2020 GMC Sierra 3500 HD All Front 1.5-2.5 $329.95
2021 GMC Sierra 3500 HD All Front 1.5-2.5 $329.95
2022 GMC Sierra 3500 HD All Front 1.5-2.5 $329.95
2023 GMC Sierra 3500 HD All Front 1.5-2.5 $329.95
2024 GMC Sierra 3500 HD All Front 1.5-2.5 $329.95
PART NUMBER 987-24-010
FEATURES 2.5” Impact extruded 6061-T6 aluminum shock body
Type II clear-anodized body plating
High-flow velocity-sensitive damping
5/8” hard chrome shaft
Internal floating piston (IFP)
Hydraulic Top Out (HTO) piston
SERIES Performance
TRAVEL 5.18
EXTENDED LENGTH 18.95
COMPRESSED LENGTH 13.76
TOP MOUNT Bar Pin
BOTTOM MOUNT Clevis
FITMENT NOTES Lift: 1.5-2.5 inches
